$950.75
Original: $3,169.17
-70%AIM-TTI INSTRUMENTS QL564TP 242W Bench Top Power Supply with a 0V-56V Output Voltage and 0A-4A Output Current—
$3,169.17
$950.75The Story
The QL Series II is the latest and highest performance linear regulated power supply series from TTi. Single and triple output models are available. Each model can be specified with or without digital remote control interfaces. Each main output provides more than 100 watts of power, and dual range capability offers higher currents at lower voltages. New features include an enhanced auxiliary output with fully variable voltage and higher current capability on T models, and an LXI compliant LAN interface on all P models.
- Dual 0-56V/4A max +1-6V/3A
- Single output or triple output models, LAN, GPIB, RS232 & USB interfaces
- LAN interface conforms with LXI class C
- Compact modular width for bench or rack, front and rear mounted terminals
- 1mV resolution at up to 56 volts
- *Multiple ranges for increased current flexibility
- Multiple non-volatile setting memories
- OVP and OCP trips with alarm output
- Selectable remote sense terminals
- Linked-mode operation of main outputs (triple)
- Auxiliary output fully variable 1.00V to 6.00V at 3A (triple)
- Full control and read-back of all outputs via the bus
Product details
| Power Supply Output Type | Adjustable |
| Warranty | 3 Years |
| Plug Type | - |
| Output Voltage Max | 56V |
| Output Voltage Min | 0V |
| Product Range | QL Series |
| Output Current Max | 4A |
| Output Current Min | 0A |
| Supply Voltage Min | 103.5VAC |
| Power Rating | 242W |
| Supply Voltage Max | 253VAC |
| No. of Outputs | 3 Output |
Other details
| Brand | AIM-TTI INSTRUMENTS |
| Part Number | QL564TP |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Manufacturer Catalogue EN | |
| Operating Instructions EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
