-70%Godox GM6S 5.5" 4K HDMI Touchscreen Ultrabright On-Camera Monitor—
$415.81
$124.74The Story
Godox GM6S Overview
- 1Description
- 2
- 3
- 4Ultrabright Screen
- 5Rec.709 Color, 3D LUT Support
- 6Interface and Control
- 7Image Monitoring Tools
- 8Multiple Power Options
Like its predecessor, the
Godox GM6S On-Camera Monitor is a compact, 5.5" device with a lightweight design but features an updated screen with 1200 cd/m² brightness. An HDMI input and output support both DCI and UHD 4K video. A camera control interface is available to communicate settings to the camera from the monitor with separately available proprietary cables. A 3.5mm headphone jack outputs audio for monitoring on set. Up to twenty-five 3D LUTS can be loaded into the monitor using the SD card slot.
Ultrabright Screen
The 5.5" monitor features a maximum brightness of 1200 cd/m² for visibility in bright daylight applications. An included sun hood further reduces glare in particularly sunlit filming locations.
Rec.709 Color, 3D LUT Support
- Rec.709 color calibration guarantees images with accurate, reliable color
- Converts Log into Rec.709
- Supports up to twenty-five 3D LUTs via SD card and compatible 17/32/33/64/65 cubic files
Interface and Control
- Five function keys can be custom programmed to toggle between various settings
- Separately available camera control cable accesses camera controls via GM6S
- Improved UI design and layout
- HDMI input/output
- Three 1/4"-20 mounting threads for accessories
Image Monitoring Tools
- Focus assist
- Zebra
- Waveform
- LUT management
- Video aspect ratio
- Center marker
- Safety marker
- Image flip
- Grid
- Audio meter
- False colors
- Monochrome
- Pixel-to-pixel
- Zoom
Multiple Power Options
- DC power input
- 7.8V DC output port for accessories
- USB-C power input
- L-series battery plate
In the Box
- Godox GM6S 5.5" 4K HDMI Touchscreen Ultrabright On-Camera Monitor
- Sun Hood
- Tilting Cold Shoe Mount
- HDMI to HDMI Cable
- HDMI to Micro-HDMI Cable
- HDMI to Mini-HDMI Cable
- Screen Cloth
- Limited 1-Year Manufacturer Warranty
Table of Contents
- Description
- Ultrabright Screen
- Rec.709 Color, 3D LUT Support
- Interface and Control
- Image Monitoring Tools
- Multiple Power Options
Godox GM6S Specs
Display
| Panel Type | IPS-Type LCD |
| Display Size | 5.5" / 14.0Â cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 160° Vertical: 160° |
| Touchscreen | Yes |
| Maximum Brightness | 1200 nits / cd/m2 |
| Contrast Ratio | 1000:1 |
| Bit Depth / Color Support | 8-Bit (16.7 Million Colors) |
| HDR Compatibility | None |
| Pixels Per Inch (ppi) | 400 ppi |
| Image Controls | Focus Assist, Image Flip, Waveform, Zebra |
| Video I/O | 1 x HDMI 1.4 Input 1 x HDMI 1.4 Output |
| Embedded Audio | HDMI |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | None |
| Power I/O | 1 x USB-C Input 1 x Barrel 5.5 mm (24 VDC) Input 1 x Barrel 5.5 mm (1.5 A / 7.8 VDC) Output |
| Other I/O | 1 x 2.5 mm Input |
| Media/Memory Card Slot | Single Slot: SD/SDHC |
| Wi-Fi | None |
Format Support
| Video Format | HDMI DCI 4K: 30/29.97/25/24/23.98 UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/50 720p: 60/50 576p: 60/50 576i: 60/50 |
| Gamma Curve | Rec709 |
Power
| DC Input Power | 7 to 24 VDC |
| Battery Type | 1 x L-Series |
| Power Consumption | 9 W |
Mounting
| Mounting | 3 x 1/4"-20 Female |
Environmental
| Operating Temperature | 14 to 122°F / -10 to 50°C |
General
| Material of Construction | Metal, Plastic |
| Dimensions | 5.7 x 3.4 x 1.1" / 14.5 x 8.7 x 2.8Â cm |
| Weight | 9.6Â oz / 273Â g |
Packaging Info
| Package Weight | 1.405 lb |
| Box Dimensions (LxWxH) | 7.2 x 5 x 4" |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
