DVDO ATRIX-88SS-VW Overview
The 4K 8x8 Seamless HDMI Matrix Switcher & Video Wall Controller from DVDO delivers seamless 8x8 matrix switching and video wall functions with resolutions up to 4K60 4:4:4 at 18 Gb/s. The unit also boasts a web browser interface for accurate configuration and control for use as a standalone device or with third-party controllers. In addition, front-panel push buttons, IR remote control, RS-232, and Web GUI provide a wide array of control options. The switcher, which is encased in a sturdy, metal 1 RU enclosure, handles all industry standard video resolutions and is compliant with HDCP 2.2. It also offers advanced EDID management, supports power-off memory, and comes with the necessary hardware for mounting the unit onto a rack.
- HDCP 2.2 compliant
- Seamless video switching
- Video inputs support all industry standard video resolutions
- HDMI outputs support resolutions up to 2160p60, 4:4:4 at 18 Gb/s
- CEC control
- Supports eight L/R balanced audio outputs
- Each output supports horizontal and vertical mirror
- Blank screen, blue screen, and output off are optional when no signal outputs
- Supports LPCM, Dolby Digital/Plus/EX, Dolby TrueHD, DTS, DTS-EX, DTS High Resolution, DTS-HD-Master Audio
- Advanced EDID management and power-off memory support
- Control via front panel, IR, RS-232, and Web GUI
- 1 RU standard height
Items Included
- DVDO 4K 8x8 Seamless HDMI Matrix Switcher & Video Wall Controller
- IR Remote
- IR Wideband Receiver Cable (5')
- USB-A to RS-232 DB9 Male Serial Cable
- 8 x 5-Pin Phoenix Connector
- 8 x Machine Screw
- 2 x Mounting Ear
- 24V, 3.75A Locking Power Adapter
- Limited 1-Year Manufacturer Warranty
Additional Resources
DVDO ATRIX-88SS-VW Specs
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
DCI 4K at 60
|
| Color Processing |
8-Bit, 10-Bit, 12-Bit 4:4:4 YCbCr
8-Bit, 10-Bit, 12-Bit 4:4:4 RGB 8-Bit, 10-Bit, 12-Bit 4:2:2 YCbCr 8-Bit, 10-Bit, 12-Bit 4:2:2 RGB 8-Bit, 10-Bit, 12-Bit 4:2:0 YUV |
| Video Inputs |
8x HDMI Female
|
| Input Video Format |
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV, YCC)
DCI 4K up to 60 fps |
| Embedded Audio Input |
HDMI: 8-Channel (per Input)
|
| Video Outputs |
8x HDMI (2.0b) Female
|
| Output Video Format |
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV, YCC)
DCI 4K up to 60 fps |
| Audio Outputs |
8x TOSLINK S/PDIF
8x Block 5-Pin Stereo Analog Male |
| Output Audio Format |
LPCM (Linear Pulse-Code Modulation)
S/PDIF Analog |
| Embedded Audio Output |
HDMI: 8-Channel (per Output)
|
| Other I/O |
1x RJ45 Control Input/Output
1x DE-9/DB-9 Control, RS-232 Input/Output 1x 1/8" / 3.5 mm IR |
| Digital Audio Decoding |
DTS-HD Master Audio, Dolby Digital Plus, Dolby Digital EX, Dolby Digital / AC3, Dolby Atmos, DTS, DTS-HD High Resolution, LPCM, Dolby TrueHD
|
| HDCP Support |
Yes, Version 2.2
|
| HDR Support |
Yes
|
| DTS Compatibility |
DTS, DTS-HD High Resolution, DTS-HD Master Audio
|
| Dolby Compatibility |
Dolby Atmos, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD
|
| Wireless |
Bluetooth / Wi-FiÂ
|
| Power I/O |
1x Barrel (24 VDC at 3.7 A) Output
|
| Power Consumption |
Device: 75 W
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 90% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°CÂ
|
| Certifications |
CE, FCC, UL
|
| Rack Form Factor |
1 U
|
| Dimensions |
17.3 x 11.8 x 1.8" / 440 x 300 x 44.5Â mm
|
| Weight |
8.71Â lb / 3.95Â kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
