Blustream HMXL42ARC Overview
Route up to four HDMI 2.0 UHD 4K inputs to up to two HDBaseT-compatible destinations with the 4x2 HDBaseT CSC Matrix Kit from Blustream. This versatile matrix switcher de-embeds audio to two digital optical ports and/or two analog 3.5mm stereo jacks. The switcher supports all known HDMI audio formats, input and output resolutions up to UHD 4K60 with 4:4:4 chroma sampling, and down-conversion on both HDBaseT outputs. An HDMI port at output 1 provides simultaneous output with that of the same output's HDBaseT.
The unit can be controlled via front-panel buttons, IR with the included remote, RS-232 via an optional controller, and TCP/IP over an RJ45 LAN port. The HDCP 2.2 compliant device boasts advanced EDID management and HDR support. The package includes two HEX70CS-RX receivers with respective mounting kits, a rack-mounting kit, and a 24 VDC, 5A power supply.
- Features four HDMI inputs, which can be independently routed to two HDBaseT outputs and one HDMI output
- Advanced Color Space Conversion (CSC) supports HDMI 2.0 18 Gb/s specification including HDR
- Supports up to UHD 4K60 4:4:4
- Video down-conversion on HDBaseT outputs allows for a display only capable of supporting lower video resolutions (4K60 4:2:0 or 1080p) to receive the native 4K60 4:4:4 video content while still showing maximum original UHD 4K resolution on remaining video outputs
- Supports all industry-standard video resolutions, including VGA-WUXGA and 480i-4K
- Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos, DTS-HD Master Audio, and DTS:X
- HDMI audio breakout to associated output analog L/R audio and optical digital outputs concurrently
- Web interface module for control and configuration of matrix
- Control via front panel, IR, RS-232, and TCP/IP
- Third-party drivers available for major control brands
- Advanced EDID management
- HDCP 2.2 compliant
- Audio breakout features selectable source from zone audio breakout or ARC from zone outputs via HDMI ARC or optical ARC
In the Box
- Blustream 4x2 HDBaseT CSC Matrix Kit
- Rackmount Kit (19")
- Surface Mount Kit
- 24 VDC, 5A Power Supply
- IR Remote Control
- 4 x IRE1 Emitter
- 3 x IRR Receiver
- Serial Cable (DB9 to 3-Pin Phoenix)
- IR Control Cable (3.5 to 3.5mm)
- 2 x HEX70CS Receiver
- 2 x Mounting Kit for HEX70CS-RX Receiver
- Limited 1-Year Manufacturer Warranty
Blustream HMXL42ARC Specs
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
UHD 4K at 60
|
| Color Processing |
4:4:4
4:2:0 |
| Video Inputs |
4x HDMI (2.0) Female
|
| Input Video Format |
HDMI (4:4:4/4:2:0)
UHD 4K up to 60 fps |
| Embedded Audio Input |
HDMI: 8-Channel (per Input)
|
| Video Outputs |
2x RJ45 (HDBaseT) Female
1x HDMI (2.0) Female |
| Output Video Format |
HDMI / RJ45 (4:4:4/4:2:0)
UHD 4K up to 60 fps |
| Audio Outputs |
2x TOSLINK 8-Channel S/PDIF Female
2x 1/8" / 3.5 mm TRS Stereo Analog Female |
| Output Audio Format |
S/PDIF
Analog |
| Embedded Audio Output |
RJ45: 8-Channel (per Output)
HDMI: 8-Channel |
| Other I/O |
1x Block 3-Pin RS-232 Input/Output
3x 1/8" / 3.5 mm IR Input 4x 1/8" / 3.5 mm IR Output |
| HDCP Support |
Yes, Version 2.2
|
| DTS Compatibility |
DTS, DTS 96/24, DTS Digital Surround, DTS Express, DTS Neo:6, DTS Neural:X, DTS Virtual:X, DTS-ES, DTS-HD Express, DTS-HD High Resolution, DTS-HD Master Audio, DTS:X, DTS:X Pro
|
| Dolby Compatibility |
Dolby Atmos, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Dual Mono, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Power I/O |
1x Barrel (24 VDC at 5 A) Input
|
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Certifications |
FCC, CE, RoHS, CANICES-3
|
| Rack Form Factor |
1 RU
|
| Dimensions |
9.3 x 8.7 x 1.7" / 235 x 220 x 44Â mm
|
