$406.12
Original: $1,353.74
-70%Accsoon CineView M7 7" Recording Monitor—
$1,353.74
$406.12The Story
Accsoon M7 Overview
Add pro cinema monitoring tools to your camera with the
CineView M7 7" Monitor from
Accsoon. This bright, 7" on-camera multi-touch display offers 1920 x 1080 resolution, 1000 cd/m? brightness, numerous imaging tools, and the ability to input and output up to DCI 4K60 video via HDMI and up to 1080p60 via 3G-SDI.
Powerful Touchscreen Display
This edge-lit LED-backlit LCD screen features a bright, multi-touch interface with 1920 x 1080 resolution that accurately monitors cinema-grade footage. It features a wide 176? viewing angle, and it is fully calibrated to 100% Rec.709 from the factory for accurate, true-to-life colors.
Versatile Input/Output
The monitor provides a 3G-SDI input and output supporting up to 1080p60 video. The HDMI 2.0 input and output support up to DCI 4K60 video. There is also a 3.5mm microphone jack to embed audio into video recording/output, and a 3.5mm headphone jack is provided with a source selector to monitor either embedded or mic input audio.
Multiple Imaging Tools
The integrated SmartOS features multiple tools to enhance your monitoring experience, including 3D LUT support, color grading, color management, waveforms, histograms, gamma settings, gain control, zebra, vectorscope, device status such as temperature and fan speed, and more.
Recording and Playback
The monitor features built-in recording via the SD card slot or the USB port for via a flash drive or external SSD storage. You can record up to 4K60 from the HDMI input or 1080p60 via the SDI input, and it supports H.264/H.265 compression and CBR/VBR control. Recordings also allow you to save files with 3D LUTs applied. The SmartOS features a file management interface for playback and management of all your recording files.
Power Options
You can power the monitor using the dual L-series/NP-F slots on the back, or you can utilize the 2.1mm barrel 16.8V input or the USB-C PD input with a separately available 9V, 3A power supply. The monitor also allows you to pass power through to a camera or external device using the 5V USB-C output.
Additional Details
- High-transparency display with antireflective DXC coating
- 1000 cd/m? brightness for easy viewing, even in outdoor environments
- High 1000:1 contrast ratio
- Customizable physical function buttons
- Optional cage with a sun hood is available separately
- Support for cinema color spaces, including 8/10-bit RGB and YUV 422/444
- 1/4"-20 mounting options on multiple sides
- Aircraft-grade aluminum chassis
- Passive and fan cooling
UPC: 607609770473
Items Included
- Accsoon CineView M7 7" Recording Monitor
- Limited 1-Year Manufacturer Warranty
Not Included
-
BatteriesEssential
Additional Resources
Firmware Updates
vN/A, Oct ' 25
Accsoon M7 Specs
Key Specs
| Display Size |
7.0" / 17.8 cm
|
| Native Resolution |
1920 x 1080
|
| Touchscreen |
Yes
|
| HDR Support |
Yes
|
| Video I/O |
1x BNC (3G-SDI) Input
1x BNC (3G-SDI) Output 1x HDMI 2.0 Input 1x HDMI 2.0 Output |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [Record/LUT/Firmware]
|
| Video Format |
HDMI
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98 UHD 4K: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SDI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 |
| Battery |
2x L-Series Mount on Fixed Plate
|
| Power Consumption |
12 W (Typical)
28 W (Maximum) |
Display
| Panel Type |
LCD
|
| Display Size |
7.0" / 17.8 cm
|
| Native Resolution |
1920 x 1080
|
| Aspect Ratio |
16:9
|
| Viewing Angle |
Horizontal: 176?
Vertical: 176? |
| Touchscreen |
Yes
|
| Maximum Brightness |
1000 nits / cd/m2
|
| Contrast Ratio |
1000:1
|
| HDR Support |
Yes
|
| Color Gamut |
100% Rec. 709
|
| LUT Support |
Yes
|
| Image Controls |
Anamorphic De-Squeeze, False Color, Focus Peaking, Histogram, Image Flip, Image Freeze, Pixel Zoom, Screen Markers, Vectorscope, Waveform, Zebra
|
Inputs/Outputs
| Video I/O |
1x BNC (3G-SDI) Input
1x BNC (3G-SDI) Output 1x HDMI 2.0 Input 1x HDMI 2.0 Output |
| Embedded Audio |
HDMI/SDI
|
| Audio I/O |
1x 1/8" / 3.5 mm Mic Input
1x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker |
No
|
| Power I/O |
1x Barrel 2.1 mm (16.8 VDC) Input
1x USB-C (9 VDC / 3 A) Input 1x USB-C (5 VDC / 2 A) Output |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [Record/LUT/Firmware]
|
Wireless
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Mobile App Compatible |
No
|
Format Support
| Video Format |
HDMI
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98 UHD 4K: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SDI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 |
| Video Signal Conversion |
SDI to HDMI
HDMI to SDI |
| Timecode Support |
No
|
Recording
| Pulldown Conversion |
No
|
| Camera Trigger |
No
|
| Pre-Roll Record |
No
|
| Encoding Formats |
Up to 4096 x 2160
H.264 Up to 4096 x 2160 H.265 |
| Maximum Audio Tracks |
2
|
Power
| Input Power |
6 to 16.8 VDC
9 to 15 VDC at 3 A |
| Battery |
2x L-Series Mount on Fixed Plate
|
| Power Consumption |
12 W (Typical)
28 W (Maximum) |
Mounting
| Tripod/Accessory Mounting |
2x 1/4"-20 Female
|
General
| Operating Conditions |
14 to 104?F / -10 to 40?C
|
| Material of Construction |
Aluminum
|
| Dimensions |
7.2 x 4.8 x 1.2" / 182.2 x 120.7 x 31.5 mm
|
| Weight |
1.1 lb / 494.3 g
|
Packaging Info
| Package Weight |
1.595 lb
|
| Box Dimensions (LxWxH) |
8.2 x 5.9 x 2.3"
|
