Teradek Serv Micro Overview
- 1Description
- 2On-Set Streaming
- 3Off-Set Streaming
- 4Postproduction Streaming
- 5Bonding
Wirelessly stream up to 1080p30 video to 10 devices via Wi-Fi using the compact Serv Micro from Teradek. Like others in the Serv video transmitter line, the Serv Micro is ideal for sharing your footage on set from production to post. This allows your videographers, editors, and producers to work in close collaboration.
The Serv Micro inputs video via HDMI, inputs audio via 3.5mm mic/line input, and streams video via Wi-Fi, Ethernet, or via a separately available USB cellular modem. It is also capable of recording the monitored stream to an SD card. A free iOS and Android compatible app allows for local sharing and messaging using the Teradek VUER app, and doesn't require an internet connection. The Serv Micro is equipped with Teradek Core compatibility for sharing globally using various devices. It also supports 256-bit encryption to ensure secure sharing. It also supports bonding on up to 7 networks, via Ethernet, Wi-Fi, and cellular.
- Connect the crew from anywhere on set with live camera feeds streamed to 10 devices or 20 when connected to a local network via the free VUER app
- Easy, customizable app monitoring tools
- True image fidelity with critical resolution and color-accuracy with low delay
- Distribute secure, 256-bit encrypted streams
- Display up to four camera feeds at once
- Share live camera feeds up to 1080p30 with remote stakeholders via the cloud to computers, TVs, smartphones, or tablets via Core
- Collaborate live via integrated messaging and voice chat
- Send up to 1080p30 video in real time to editors, colorists, VFX teams, directors, and other remote collaborators with Core
- Send streams through the cloud to anymore in your production
- Ethernet
- Wi-Fi
- USB cellular modem
- Up to 4 smartphones (iOS or Android)
In the Box
- Teradek Serv Micro
- Mini-HDMI Type C to HDMI Type A (18")
- Ethernet Cable
- 18W Power Adapter
- Shoe Mount Adapter
- 2 x Antenna
- Limited 1-Year Manufacturer Warranty
- Description
- On-Set Streaming
- Off-Set Streaming
- Postproduction Streaming
- Bonding
Teradek Serv Micro Specs
| Antenna I/O | 2 x RP-SMA |
| Video I/O | 1 x HDMI 2.0 Input |
| HDCP Support | Not Specified by Manufacturer |
| Embedded Audio | Not Specified by Manufacturer |
| Audio I/O | 1 x 1/8" / 3.5 mm Mic/Line Input |
| Power I/O | 1 x Barrel Input |
| Other I/O | 1 x USB-A 2.0 Input/Output 1 x RJ45 (10/100 Mb/s Ethernet) Input/Output |
| Media/Memory Card Slot | Single Slot: SD/SDHC |
| # of Channels | 10 |
| Wi-Fi | Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) |
| Bluetooth | None |
| Video Format | HDMI (8-Bit 4:2:0) 1080p: 30 |
| Timecode Support | No |
| DC Input Power | 28 VDC |
| Battery Type | 1 x L-Series |
| Power Consumption | 6 W |
| Mounting | Not Specified by Manufacturer |
| Environmental Protection | None |
| Dimensions | 4.1 x 3 x 1.1" / 105 x 75 x 28Â mm |
| Weight | 6.7Â oz / 190Â g |
| Package Weight | 1.865 lb |
| Box Dimensions (LxWxH) | 7.1 x 6.5 x 4.8" |
