The Story
Planar Systems PLL2450MW Overview
With built-in TrueMedia speakers, the PLL2450MW 24" 16:9 LCD Monitor from Planar Systems offers an intuitive multimedia viewing experience. Aside from the 1W speakers, this monitor features a Full HD 1920 x 1080 resolution with a 3000:1 contrast ratio and 178° horizontal and vertical viewing angles, making it easy to see the display from virtually any angle. Installation is simple thanks to HDMI and VGA inputs, allowing this monitor to be plugged in to virtually any computer configuration. Additionally, the monitor can be mounted to the wall using a VESA compatible wall mount or attached to the included stand, which allows viewers to tilt the display from -5 to 20° for an optimal viewing experience.
- 23.6" LCD monitor with 1920 x 1080 resolution
- HDMI and VGA video inputs
- Wide viewing angles (178°/178°)
- Compatible with mounting options that use 100mm VESA mount
- Blue light reduction
- Flicker free
- Recommended usage of 16 hours per day
- Anti-glare coating
- Multi-language display
- On-screen display (OSD)
- Kensington security slot
In the Box
- Planar Systems PLL2450MW 24" 16:9 LCD Monitor
- Power Cord
- HDMI Cable
Planar Systems PLL2450MW Specs
| Size | 23.6" |
| Screen Area | 20.52 x 11.4" / 52.12 x 29.0 cm |
| Panel Type | LCD |
| Touchscreen | No |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Pixels Per Inch (ppi) | 93 ppi |
| Finish | Anti-Glare / Matte |
| Maximum Brightness | 250 cd/m2 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 60 Hz |
| Variable Refresh Technology | None |
| Bit Depth / Color Support | 6-Bit+FRC (16.7 Million Colors) |
| HDR Compatibility | None |
| Response Time | 12.5 ms (GtG) |
| Viewing Angle (H x V) | 178 x 178° |
| Dot Pitch | 0.2715 x 0.2715 mm |
| Inputs/Outputs | 1 x HDMI Input 1 x VGA Input 1 x 1/8" / 3.5 mm Output 1 x 1/8" / 3.5 mm Input |
| HDCP Support | Yes |
| Built-In Speakers | Yes, 2 x 1 W |
| Media Card Reader | None |
| Multi-Input Support (PIP/PBP) | None |
| Power Consumption | 18.5 W (Typical) 0.5 W (Standby) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type | Internal |
| USB Power Delivery | None |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Operating Humidity | 10 to 90% (Non-Condensing) |
| Certifications | FCC-B, RoHS, UL, cUL *as per Manufacturer |
| Height Adjustment | None |
| Rotation Adjustment | None |
| Swivel Adjustment | None |
| Tilt Adjustment | -5 to 20° |
| Max Arm Extension Length | None |
| Mounting-Hole Pattern | 100 x 100 mm |
| Lock Slot | Yes, Kensington |
| Dimensions (W x H x D) | 21.6 x 16.0 x 6.7" / 547.6 x 405.5 x 170.4 mm (with Stand) 21.6 x 16.0 x 1.6" / 547.6 x 405.5 x 40.9 mm (without Stand) |
| Weight | 6.9 lb / 3.1 kg (with Stand) 6.4 lb / 2.9 kg (without Stand) |
| Package Weight | 10.05 lb |
| Box Dimensions (LxWxH) | 24.1 x 15.8 x 5.4" |
