PANASONIC EEEFK1E102AQ SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar
HomeStore

PANASONIC EEEFK1E102AQ SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar

PANASONIC EEEFK1E102AQ SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar

$0.77

Original: $2.57

-70%
PANASONIC EEEFK1E102AQ SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar—

$2.57

$0.77

The Story

The EEEFK1E102AQ is a surface-mount medium-size aluminium Electrolytic Capacitor features high reliability, long life, low impedance and high ripple current of the top-class in AL-E. The FK-V series aluminium electrolytic capacitor is applied to an in-vehicle electric equipment and the anti-vibration type (more than �8mm) can support.
  • Sheathless (metal case) appearance

Product details

Capacitor Case / Package: Radial Can - SMD
Capacitance: 1000µF
Voltage(DC): 25V
ESR: -
Lifetime @ Temperature: 5000 hours @ 105°C
Polarity: Polar
Product Range: FK
Capacitance Tolerance: ± 20%
Capacitor Terminals: Solder
Product Diameter: 12.5mm
Product Length: -
Product Width: -
Product Height: 13.5mm
Ripple Current: 1.1A
Operating Temperature Min: -55°C
Operating Temperature Max: 105°C
Qualification: AEC-Q200
MSL: -

Other details

Brand PANASONIC
Part Number EEEFK1E102AQ
Quantity Each (Supplied on Cut Tape)
Technical Data Sheet EN Download technical document - datasheet - Tanotis India

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.

Description

The EEEFK1E102AQ is a surface-mount medium-size aluminium Electrolytic Capacitor features high reliability, long life, low impedance and high ripple current of the top-class in AL-E. The FK-V series aluminium electrolytic capacitor is applied to an in-vehicle electric equipment and the anti-vibration type (more than �8mm) can support.
  • Sheathless (metal case) appearance

Product details

Capacitor Case / Package: Radial Can - SMD
Capacitance: 1000µF
Voltage(DC): 25V
ESR: -
Lifetime @ Temperature: 5000 hours @ 105°C
Polarity: Polar
Product Range: FK
Capacitance Tolerance: ± 20%
Capacitor Terminals: Solder
Product Diameter: 12.5mm
Product Length: -
Product Width: -
Product Height: 13.5mm
Ripple Current: 1.1A
Operating Temperature Min: -55°C
Operating Temperature Max: 105°C
Qualification: AEC-Q200
MSL: -

Other details

Brand PANASONIC
Part Number EEEFK1E102AQ
Quantity Each (Supplied on Cut Tape)
Technical Data Sheet EN Download technical document - datasheet - Tanotis India

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
