The Story
Designed for use in secure defense and intelligence applications, this SKMN-4S 4-Port USB KM Switch with Audio from IPGard features mechanical, electrical and optical signal isolation to prevent hacking and data leakage. It controls data relays using inverted signals, shielding connections from outside intrusion by forcing them to work one at a time. Each port uses its own isolated data channel and each unit features non-reprogrammable ROM to protect the switch's functions. The switch emulates the presence of a keyboard and a mouse for every attached computer through a USB cable, preventing direct connection between the peripherals and the connected computer.
-
- Mouse switching technology
- Supports Windows, Mac and Linux OS
- Supports balanced speaker output and audio switching
- Front panel tactile buttons with LED indicator
- External power supply (Level VI efficiency)
- Non-reprogrammable ROM
- Active anti-tamper switches
- Long-life internal anti-tampering battery
- External tamper-evident seals
- Keyboard and mouse emulation
- Certified by NIAP (Protection profile for Peripheral Sharing Switch Version 3.0)
- Applications
-
- Government operations
- Defense applications
- Secure control rooms
- Corporate communications
- Server operations
- Educational administrations
- Medical facilities
- Banking network
- Insurance data centers
- Transit management
- Industrial operations
- Intelligence communicationsÂ
Â
IPGard SKMN-4S specs
| USB | |
|---|---|
| Input Interface | 4 x USB type B |
| Output Interface | 2 x USB 1.1 type A for KM devices |
| Emulation | Keyboard and mouse |
| Audio | |
|---|---|
| Audio Input | 4 x 3.5 mm stereo audio |
| Audio Output | 1 x 3.5 mm stereo audio |
| General | |
|---|---|
| Max Computer Connections | 4 |
| Panel | Front panel SELECT buttons |
| Power | External 100 to 240 VAC / 12 VDC 2A at 24 W |
| Approvals | NIAP PP 3.0, UL, CE, and RoHS compliant |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Humidity | Up to 80% (no condensation) |
| Dimensions | 12.6 x 1.8 x 6.7" / 32 x 4.6 x 17 cm |
| Weight | 4.2 lb / 1.9 kg |
- PS12V2A Power Adapter
- Limited 1-Year Warranty
