$18.57
Original: $61.91
-70%Cinch Connectivity Solutions MS24264R8B3PN-LC MS24264R8B3PN-LC Circular Connector MIL-DTL-26500 Series Wall Mount Receptacle 3 Contacts—
$61.91
$18.57The Story
The MS24264R8B3PN-LC from Cinch is MIL-DTL-26500 series wall mount receptacle with 3 contacts. These connectors are available with variety of shell and finishes which are used in some of the most rugged environments and must perform flawlessly under wide temperature ranges, high vibrations and resistant to contaminants. It withstands high vibration and suitable for quick disconnect applications.
- 500 mating cycles
- Styles qualified to Boeing BACC45 series
- Crimp front release contacts
- Optional fixed contacts, PC termination
- High reliability, minimum insulation resistance of 5000Mohm
- Environmentally sealed, ozone resistance of 0.015% by volume
- Operates at extreme temperature range from -55°C to +200°C
- Aluminium alloy body material with non-conductive black anodized finish
- Copper alloy crimp pin contacts with gold plating
Aerospace, Defence, Military, Industrial
Other details
| Brand | CINCH CONNECTIVITY SOLUTIONS |
| Part Number | MS24264R8B3PN-LC |
| Quantity | Each |
| Technical Data Sheet EN |  |
