$7.09
Original: $23.62
-70%Belden 83265 Coaxial Cable Per Metre High Temperature MIL-C-17 RG178B 30 AWG 50 ohm—
$23.62
$7.09The Story
This is the cut to length part of 83265-100-9 and is available to be ordered by the metre to your specified length. This is a RG178B high temperature Coaxial Cable with 30AWG stranded (7 x 38) silver-plated copper-covered steel conductor, TFE PTFE insulation, silver-plated copper braid shield (95% coverage) and white FEP jacket. This coaxial cable is perhaps the most common, basic and easy-to-understand cables. Basically, they are used to transmit electrical energy or signals, from one location to another, to connect a source to a load, such as a transmitter to an antenna. Coaxial cable (coax) is typically identified or classified according to its impedance or RG-type. Belden« coaxial cable is tested with equipment that simulates every known environmental and electrical performance condition. As a result, this cable can be counted on for positive, reliable and trouble-free operation.
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
- CPR: Not Yet Qualified
- 50R Impedance
- 29pF/ft Conductor to shield nominal capacitance
- 69.5% Nominal velocity of propagation
- 244R/1000ft at 20?C Nominal conductor DC resistance
- 14.6R/1000ft at 20?C Nominal outer shield DC resistance
Communications & Networking
Product details
| Coaxial Cable Type | RG178B |
| Wire Gauge | 30AWG |
| Conductor Area CSA | - |
| Impedance | 50ohm |
| Reel Length (Imperial) | - |
| Reel Length (Metric) | - |
| Jacket Colour | White |
| Jacket Material | FEP |
| Conductor Material | SPCCS (Silver Plated Copper Coated Steel) |
| No. of Max Strands x Strand Size | 7 x 38AWG |
| External Diameter | 1.8mm |
| Product Range | 83265 Coax |
Other details
| Brand | BELDEN |
| Part Number | 83265 |
| Quantity | 1Â Metre |
| Technical Data Sheet EN |  |
