-70%XP POWER IL2403S 2 Watt SIP Single Output DC/DC Converter, Input 24V, Output 3.3V/400mA—
$14.53
$4.36The Story
This is a 2 Watt SIP Single Output DC/DC Converter, Input 24V, Output 3.3V/400mA product from XP POWER with the model number IL2403S
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 2W |
| Output Voltage - Output 1 | 3.3V |
| Output Current - Output 1 | 400mA |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | XP IL Series |
| Input Voltage DC Min | 21.6V |
| Input Voltage DC Max | 26.4V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 7.5mm |
| Height | 10.16mm |
| Depth | 11.68mm |
Other details
| Brand | XP POWER |
| Part Number | IL2403S |
| Quantity | Each |
| Technical Data Sheet EN |  |
