$109.19
Original: $363.97
-70%Weidmuller 1478130000 AC/DC DIN Rail Power Supply (PSU) ITE 1 Output 240 W 24 VDC 10 A—
$363.97
$109.19The Story
The 1478130000 from Weidmuller is a 240W, 24V & 10A switch mode power supply unit. It features horizontal on TS35 mounting rail, 50mm of clearance at top & bottom for air circulation, can mount side by side with no space in between and LED red/green and relay (>=21.6 V DC LED green, relay on/ <= 20.6 LED red, relay off) status indication.
- Dimension is 60mm x 130mm x 125mm ( W x H x D)
- Operating temperature range from -25°C to 70°C
- Screw connection, III surge voltage category
- Current limiting is greater than 120% IN
- Degree of efficiency is 91.5%
- Metal, corrosion resistant housing version, MTBF >500.000h (25°C, IEC 61709)
- IP20 protection degree
- Conductor cross section range from 26AWG to 10AWG (input) and 26AWG to 10AWG (output)
- GERMLLOYD 14076-15, cULus E258476, cULusEX E470829VOL1SEC2, cURus E255651 approved
- Series switching capability and short circuit protection
System Monitoring
Other details
| Brand | WEIDMULLER |
| Part Number | 1478130000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Description
The 1478130000 from Weidmuller is a 240W, 24V & 10A switch mode power supply unit. It features horizontal on TS35 mounting rail, 50mm of clearance at top & bottom for air circulation, can mount side by side with no space in between and LED red/green and relay (>=21.6 V DC LED green, relay on/ <= 20.6 LED red, relay off) status indication.
- Dimension is 60mm x 130mm x 125mm ( W x H x D)
- Operating temperature range from -25°C to 70°C
- Screw connection, III surge voltage category
- Current limiting is greater than 120% IN
- Degree of efficiency is 91.5%
- Metal, corrosion resistant housing version, MTBF >500.000h (25°C, IEC 61709)
- IP20 protection degree
- Conductor cross section range from 26AWG to 10AWG (input) and 26AWG to 10AWG (output)
- GERMLLOYD 14076-15, cULus E258476, cULusEX E470829VOL1SEC2, cURus E255651 approved
- Series switching capability and short circuit protection
