-70%Vishay SMDY1681MY5UCR Ceramic Suppression Capacitor 680 pF SMD Y1 Series ± 20% X1 / 760 V 500—
$2.47
$0.74The Story
SMD Y1 series AC line rated ceramic disc capacitors. The capacitor consists of a ceramic disc which is copper plated on both sides. Encapsulation is made of flame retardant epoxy resin in accordance with UL 94 V-0. Approved by IEC 60384-14.4, UL 60384-14, DIN EN 60384-14, CSA E60384-1:03, CSA E60384-14:09 and CQC11-471112-2009.
- Complying with IEC 60384-14 4th edition
- High moisture sensitive level: MSL1
- Humidity class IIB annex I achieved
- Single layer AC disc safety capacitors
- Used for X1, Y1 according to IEC 60384-14.4, across-the-line, line by-pass, antenna coupling
- Class X1, 760VAC, class Y1, 500VAC
- Climatic category (according to EN 60058-1) Class 2: 55/125/21
- Reinforced insulation
Other details
| Brand | VISHAY |
| Part Number | SMDY1681MY5UCR |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| CAD Multiple Formats EN | |
