-70%TRACOPOWER TMR 3-2423 Isolated Board Mount DC/DC Converter, Regulated, 2 Output, 3 W, 15 V, 100 mA, -15 V, 100 mA—
$33.85
$10.15The Story
The TMR 3-2423 is a 2-output board-mount isolated DC to DC Converter with fully regulated output voltage and wide 2:1 input voltage range. The TMR-3 series 3W isolated DC/DC converter comes with a small footprint and excellent efficiency. The compact dimensions of this converter make it an ideal solution for many space critical applications.
- 1500VDC I/O Isolation
- High efficiency up to 85%
- Short-circuit protection
- Remote on/off control
- -40 to +85°C Operating temperature range
Applications
Power Management, Communications & Networking, Industrial
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 100mA |
| Depth | 21.8mm |
| Width | 9.2mm |
| Product Range | TMR 3 Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 100mA |
| Height | 11.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 3-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
