-70%TRACOPOWER TMLM 04115 AC/DC PCB Mount Power Supply (PSU), Module, 1 Output, 4 W, 15 V, 267 mA—
$29.30
$8.79The Story
The TMLM series single/dual-output PCB mount AC/DC Power Module offers highest power density in a fully encapsulated module which can be soldered directly on to PCBs. This feature makes these modules an ideal solution for all space critical applications. International safety approvals qualify the product for worldwide markets. SMD-technology and high efficiency guarantees a high reliability of these power supplies.
- Universal input
- High efficiency
- Low ripple and noise
- Highest power density
- Fully encapsulated plastic case
- Short-circuit and overload protection
Applications
Power Management, Commercial
Product details
| Power Supply Output Type | Fixed |
| Output Power Max | 4W |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Input Voltage AC Max | 264V |
| Depth | 36.5mm |
| Width | 27mm |
| Input Voltage AC Min | 90V |
| Product Range | TMLM Series |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| Output Current - Output 1 | 267mA |
| Height | 17.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMLM 04115 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Handling Instructions EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Description
The TMLM series single/dual-output PCB mount AC/DC Power Module offers highest power density in a fully encapsulated module which can be soldered directly on to PCBs. This feature makes these modules an ideal solution for all space critical applications. International safety approvals qualify the product for worldwide markets. SMD-technology and high efficiency guarantees a high reliability of these power supplies.
- Universal input
- High efficiency
- Low ripple and noise
- Highest power density
- Fully encapsulated plastic case
- Short-circuit and overload protection
Applications
Power Management, Commercial
Product details
| Power Supply Output Type | Fixed |
| Output Power Max | 4W |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Input Voltage AC Max | 264V |
| Depth | 36.5mm |
| Width | 27mm |
| Input Voltage AC Min | 90V |
| Product Range | TMLM Series |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| Output Current - Output 1 | 267mA |
| Height | 17.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMLM 04115 |
| Quantity | Each |
| Technical Data Sheet EN | |
| Handling Instructions EN | |
