$7.72
Original: $25.73
-70%TRACOPOWER TEL 3-2422 Isolated Board Mount DC/DC Converter, 2 Output, 3 W, 12 V, 125 mA, -12 V, 125 mA—
$25.73
$7.72The Story
The TEL 3-2422 is a 2-output board-mount isolated DC to DC Converter with wide 2:1 and 3:1 input voltage ranges. The TEL 3 series 3W converter features low output noise and high efficiency at full load.
- Indefinite short-circuit protection
- High efficiency up to 81%
- 1500VDC I/O Isolation
- <60mV pk-pk Typical output ripple and noise
- -40 to +85�C Operating temperature range
Applications
Industrial, Consumer Electronics
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -12V |
| Output Current - Output 2 | 125mA |
| Depth | 32mm |
| Width | 20mm |
| Product Range | TEL 3 Series |
| DC / DC Converter Type | DIP |
| Approvals & Standards | CSA, IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 125mA |
| Height | 10.2mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEL 3-2422 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
