Traco Power TMR 1-2412 TMR 1-2412 Isolated Through Hole DC/DC Converter ITE 2:1 1 W Output 12 V 83 mA

The TMR 1-2412 is an isolated 1W DC-DC Converter Module with regulated output, featuring wide 2:1 input voltage ranges. It offers 18 to 36VDC input voltage range and 12VDC output voltage. The device comes with small footprint occupying only 1.2cm² of board space. An excellent efficiency allows -40 to 85°C operation temperature. Further features include remote ON/OFF control and continuous short-circuit protection.

• Fully regulated outputs
• No minimum load required
• Continuous short-circuit protection
• 1500VDC I/O isolation
• 80% Typical efficiency
• 12VDC Nominal input voltage

Applications

Communications & Networking, Sensing & Instrumentation, Consumer Electronics

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	TRACO POWER
Part Number	TMR 1-2412
Quantity	Each
Technical Data Sheet EN
CAD Multiple Formats EN
