-70%TRACO POWER TME 0503S Isolated Through Hole DC/DC Converter, 1:1, 1 W, 1 Output, 3.3 V, 260 mA—
$12.23
$3.67The Story
TME series is a range of sub-miniature, isolated DC/DC-converters in a SIP package, which requires only 0.7cm² of board space. They provide a cost effective solution to generate supplementary, isolated voltages. Full SMD-design and a 100% production test of parameters ensure a high reliability of this product.
- I/O isolation voltage of 1000VDC
- Unregulated device
- High efficiency
- Operating temperature range from -40°C to +85°C
- Industry standard pinout
- 100% burn-in (8h)
- 3-year product warranty
- Non conductive black plastic (UL 94-V0 rated) casing
- Switching frequency of 50KHz to 110KHz (frequency modulation)
- Ripple and noise (20MHz bandwidth) of 150mVp-p maximum
Product details
| Power Supply Applications: - |
| Input Ratio: 1:1 |
| Output Power Max: 1W |
| No. of Outputs: 1 Output |
| Output Voltage - Output 1: 3.3V |
| Output Current - Output 1: 260mA |
| Output Voltage - Output 2: - |
| Output Current - Output 2: - |
| Output Regulation: Unregulated |
| Isolation Voltage: 1kV |
| DC / DC Converter Type: SIP |
| Input Voltage DC Nom: 5V |
| DC / DC Converter Output Type: Fixed |
| Width: 6.1mm |
| Height: 10.2mm |
| Depth: 11.5mm |
| Input Voltage DC Min: 4.5V |
| Input Voltage DC Max: 5.5V |
| Product Range: TME Series |
Other details
| Brand | TRACO POWER |
| Part Number | TME 0503S |
| Quantity | Each |
| Technical Data Sheet EN |  |
