TRACO POWER THN 30-4811WI Isolated Through Hole DC/DC Converter, ITE, 4:1, 30 W, 1 Output, 5 V, 6 A

The THN 30-4811WI is a high performance DC/DC Converter Module with highest power density. The device achieves 30W output power, it offers 18 to 75VDC input voltage range and 5VDC output voltage. It has an ultra wide 4:1 input voltage range and precisely regulated output voltages, even under no load conditions. Highest efficiency across full load range makes this device very reliable and applicable in temperature ranges of up to 85°C. With a low input current at minimal load and remote ON/OFF control these converters are the ideal solution for battery-operated systems. The converter is suitable for use in industrial electronics and many applications where space on the PCB is critical.

• Shielded metal case with isolated base plate
• Overtemperature protection
• Ultra low no load input current
• Output voltage adjustable
• 1500VDC I/O isolation voltage
• 90% Typical efficiency
• 48VDC Nominal input voltage

Applications

Consumer Electronics, Sensing & Instrumentation, Communications & Networking, Power Management
