TRACO POWER TEC 2-1211 Isolated Through Hole DC/DC Converter, ITE, SIP, 2:1, 2 W, 1 Output, 5 V
HomeStore

TRACO POWER TEC 2-1211 Isolated Through Hole DC/DC Converter, ITE, SIP, 2:1, 2 W, 1 Output, 5 V

TRACO POWER TEC 2-1211 Isolated Through Hole DC/DC Converter, ITE, SIP, 2:1, 2 W, 1 Output, 5 V

$4.63

Original: $15.42

-70%
TRACO POWER TEC 2-1211 Isolated Through Hole DC/DC Converter, ITE, SIP, 2:1, 2 W, 1 Output, 5 V—

$15.42

$4.63

The Story

Product details

Technical Specifications

Find similar products
Power Supply Applications

ITE

Input Ratio
2:1
Open menu
No. of Outputs
1 Output
Open menu
Output Current - Output 1
400mA
Open menu
Output Current - Output 2
67mA
Open menu
Isolation Voltage

1.6kV

DC / DC Converter Output Type

Fixed

Height

11.2mm

Input Voltage DC Min
9V
Open menu
Product Range

TEC 2 Series

Find similar products
DC / DC Converter Type

SIP

Output Power Max

2W

Output Voltage - Output 1
5V
Open menu
Output Voltage - Output 2
-15V
Open menu
Output Regulation

Regulated

Input Voltage DC Nom
12V
Open menu
Width

9.1mm

Depth

21.8mm

Input Voltage DC Max
18V
Open menu

Other details

Brand TRACO POWER
Part Number TEC 2-1211
Quantity Each
Technical Data Sheet EN Download technical document - datasheet - Tanotis India
