RASPBERRY-PI SC0926 SC0926 Global Shutter Camera IMX296LQR-C Raspberry Pi Computers That has a CSI Connector New

The Global Shutter Camera is a specialised camera module designed for capturing rapid motion without distortion, making it ideal for high speed photography and machine vision applications. The camera features a Sony IMX296 1.6MP sensor that utilises the same C/CS lens mounting as the Raspberry Pi High Quality Camera. The camera delivers a large pixel size of 3.45µm x 3.45µm and can operate with exposure times as low as 30µs (with adequate lighting).

• Sony IMX296LQR-C 1.6MP sensor
• Large 3.45x3.45µm pixel size
• 6.3mm Diagonal sensor size
• RAW10 output
• Integrated IR filter
• C-Mount, camera includes a C to CS-Mount adaptor
• Compatible with all Raspberry Pi models with full size CSI camera connector
• 150mm Ribbon cable included

Contents

Camera module and C-CS mount adaptor

Footnotes Note: IR Filter can be removed to enable IR sensitivity, but this modification is irreversible.

Product details

Silicon Manufacturer	Sony
Core Architecture	-
Core Sub-Architecture	-
Silicon Core Number	IMX296LQR-C
Silicon Family Name	-
For Use With	Raspberry Pi Computers that have a CSI Connector
Kit Contents	IMX296LQR-C Sensor, C-CS Mount Adapter, Screwdriver, 150mm Ribbon Cable, Plastic Back Cover
Product Range	-

Other details

Brand	RASPBERRY-PI
Part Number	SC0926
Quantity	Each
Technical Data Sheet EN
