PHOENIX CONTACT 1792252 Pluggable Terminal Block, 5.08 mm, 3 Ways, 24AWG to 12AWG, 2.5 mm², Screw, 12 A GTIN UPC EAN: 4017918044732 MVSTBR 2,5/ 3-ST-5,08
PHOENIX CONTACT 1792252 Pluggable Terminal Block, 5.08 mm, 3 Ways, 24AWG to 12AWG, 2.5 mm², Screw, 12 A GTIN UPC EAN: 4017918044732 MVSTBR 2,5/ 3-ST-5,08
$1.48
Original: $4.93
-70%PHOENIX CONTACT 1792252 Pluggable Terminal Block, 5.08 mm, 3 Ways, 24AWG to 12AWG, 2.5 mm², Screw, 12 A GTIN UPC EAN: 4017918044732 MVSTBR 2,5/ 3-ST-5,08—
$4.93
$1.48The Story
The 1792252 is a 3-position green pluggable PCB Terminal Block with tin-plated solder contacts, a polyamide insulator and the M3 screw connection. This MVSTBR 2,5/ 3-ST-5,08 terminal block has fully developed contact geometries and surfaces. It accepts 24 to 12AWG wire range.
- MSTB plugs for vertical plug-in direction
- Conductor entry on the coding side of the plug
- 7mm Stripping length
- A3 Internal cylindrical gage
- UL94V-0 Flammability rating
Applications
Industrial
Product details
| Pitch Spacing: 5.08mm |
| No. of Positions: 3Ways |
| Wire Size (AWG): 24AWG to 12AWG |
| Conductor Area CSA: 2.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 12A |
| Rated Voltage: 320V |
| Product Range: MVSTBR |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1792252 |
| Quantity | Each |
| Technical Data Sheet EN |  |
