$2.22
Original: $7.41
-70%Omron Electronic Components G2RL-24-CF- DC24 General Purpose Relay G2RL Series Power Non Latching Dpdt 24 VDC 1.5 A—
$7.41
$2.22The Story
The G2RL-24-CF-DC24 is a fully sealed Power PCB Relay with AgNi cadmium-free contacts, DPDT contact configuration and through-hole PCB straight termination. The G2RL series general-purpose high-capacity low profile power relay is ideal for incorporation in miniature equipment.
- High capacity
- Cadmium-free contacts ensuring environment-friendly use
- Class F coil insulation
- 8A at 250VAC/30VDC Rated resistive load
- 400mW Coil power consumption
- 5000VAC Dielectric strength (AC for 1 minute)
- 10000V Impulse withstanding voltage
- 100mR Maximum contact resistance
- 1000MR Minimum insulation resistance
Consumer Electronics, Industrial
Other details
| Brand | OMRON ELECTRONIC COMPONENTS |
| Part Number | G2RL-24-CF- DC24 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
