Original: $37.34
-70%$37.34
$11.20The Story
Product Overview
The PDT006A0X3-SRZ is a 33W non-isolated DC/DC Power Module delivers up to 6A of output current. This DC/DC converter operate over a wide range of input voltage from 3 to 14.4VDC and provide a precisely regulated output voltage from 0.45 to 5.5VDC, programmable via an external resistor and further adjustable through PMBus. Features include a digital interface using the PMBus protocol, remote ON/OFF, adjustable output voltage, over current and over-temperature protection. The PMBus interface supports a range of commands to control and monitor the module. The Tunable Loopďż˝ feature allows the user to optimize the dynamic response of the converter to match the load with reduced amount of output capacitance leading to savings on cost and PWB area.
- DOSA based
- Digital interface through the PMBus protocol
- Tunable Loop to optimize dynamic output voltage response
- Flexible output voltage sequencing EZ-SEQUENCE
- Power good signal
- Fixed switching frequency with capability of external synchronization
- Output over-current protection (non-latching)
- Over-temperature protection
- Remote ON/OFF
- Ability to sink and source current
- Cost efficient open frame design
Applications
Power Management, Industrial, Communications & Networking
Product details
Other details
| Brand | OMNION POWER |
| Part Number | PDT006A0X3-SRZ |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
