MURATA POWER SOLUTIONS MGJ2D241509SC Isolated Board Mount DC/DC Converter, Gate Drive, Fixed, 2 Output, 21.6 V, 26.4 V, 2 W, 15 V

This is a Isolated Board Mount DC/DC Converter, Gate Drive, Fixed, 2 Output, 21.6 V, 26.4 V, 2 W, 15 V product from MURATA POWER SOLUTIONS with the model number MGJ2D241509SC

Product details

Output Power Max	2W
Input Voltage DC Min	21.6V
DC / DC Converter Mounting	Through Hole
Output Voltage - Output 2	-8.7V
Output Current - Output 2	40mA
Depth	19.65mm
Width	9.95mm
Product Range	MGJ2 Series
DC / DC Converter Type	SIP
Approvals & Standards	-
Output Voltage - Output 3	-
Output Voltage - Output 1	15V
Output Current - Output 3	-
DC / DC Converter Output Type	Fixed
No. of Outputs	2 Output
Input Voltage DC Max	26.4V
Output Current - Output 1	80mA
Height	12.65mm

Other details

Brand	MURATA POWER SOLUTIONS
Part Number	MGJ2D241509SC
Quantity	Each
Technical Data Sheet EN
3D Product Image EN
Product Change Notice EN
