$0.09
Original: $0.31
-71%Multicomp PRO MCRNLA06G0103B0E MCRNLA06G0103B0E Fixed Network Resistor 10 Kohm Bussed 5 Elements SIP 6 Pins PC Pin—
$0.31
$0.09The Story
The Multicomp Pro MCRNL series are thick film, low profile resistor network in single inline package. The resistance value includes E24 decade values from 10 ohm to 1Mohm. The number of resistor networks and configuration type are selected based on part numbering.
- Maximum working voltage of 100V
- ±2% and ±5% tolerance
- Temperature coefficient is ±200ppm/°C (50 ohm to 1Mohm) and ±250ppm/°C (<50 ohm and >1Mohm)
- High reliability
- Miniature, high density packaging
- Power rating of 0.2W and 0.125W available
- Operating temperature ranges from -50°C to +125°C
- Multicomp Pro products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
Product details
| Resistance | 10kohm |
| Network Circuit Type | Bussed |
| No. of Elements | 5Elements |
| Resistor Case / Package | SIP |
| No. of Pins | 6Pins |
| Resistor Terminals | PC Pin |
| Resistance Tolerance | ± 2% |
| Voltage Rating | 100V |
| Power Rating per Element | - |
| Temperature Coefficient | ± 200ppm/°C |
| Product Range | - |
| Automotive Qualification Standard | - |
Other details
| Brand | MULTICOMP PRO |
| Part Number | MCRNLA06G0103B0E |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Technical Data Sheet EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
