MOLEX 173109-0075 D Sub Connector, Standard, Plug, 173109 Series, 9 Contacts, DE, Through Hole—
$11.45
The Story
173109-0075 is a 173109 series, shielded, FCT standard-density, male D-Sub connector. Mates with FCT standard-density D-Sub, Size 1, 9 position, socket.
- 7.5A maximum current per contact
- 2 row, 9 circuits (maximum) and 9 circuits (loaded)
- Durability of 500 mating cycles max
- Copper alloy contact, gold over nickel contact plating
- White PBT resin
- Straight orientation and through hole termination style
- Steel shell and tin shell plating
- IP20 waterproof / dustproof
- Operating temperature range from -55° to +125°C
Product details
| D Sub Connector Type: Standard |
| Gender: Plug (View Associated Connectors) |
| Product Range: 173109 Series |
| No. of Contacts: 9Contacts |
| D Sub Shell Size: DE |
| Contact Termination Type: Through Hole |
| Connector Mounting: Panel Mount |
| Contact Material: Brass |
| Contact Plating: Gold Plated Contacts |
| Connector Body Material: Steel Body |
Other details
| Brand | MOLEX |
| Part Number | 173109-0075 |
| Quantity | Each |
| Technical Data Sheet EN |  |
