Mean Well NPB-120-24XLR NPB-120-24XLR Battery Charger 3 Pin Connector Desktop Lead Acid Li-Ion 264 V in 28.8 Out New

NPB-120-24XLR is a NPB-120 series charger for compatible with lead-acid (flooded, gel, AGM) and li-ion (lithium iron, lithium manganese) batteries. This product is a class I power unit (with FG), equipped with a standard IEC320-C14 AC inlet and two or three-stage charging control. Typical applications are radio system backup solution, electric scooter charger, camping car, buses, heavy duty truck, specialty vehicles, surveillance system, portable power tools.

• 90~264VAC universal AC input, built-in PFC, single output
• Charger for compatible with lead-acid and li-ion batteries
• Fanless design, wide adjustable output range, 2 or 3 stage selectable by DIP S.W
• No load power consumption is < 0.15W(AC S.W off), 3 pin power pin output connector
• Wide operating temperature range from -30°C to +70°C
• Short circuit / overvoltage /overtemperature / battery reverse polarity protection
• Comply with UL/EN62368-1 and EN60335-1/2-29 dual certification
• Front panel LED indicator for charging status, 3 years warranty
• 120W output power, 28.8V output voltage, 4A output current
• Dimension is 96mm width x 49mm height x 180mm depth

Other details

Brand	MEAN WELL
Part Number	NPB-120-24XLR
Quantity	Each
Technical Data Sheet EN
