MEAN WELL MDS02N-05N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 5 V
HomeStore

MEAN WELL MDS02N-05N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 5 V

MEAN WELL MDS02N-05N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 5 V

$2.75

Original: $9.18

-70%
MEAN WELL MDS02N-05N Isolated Through Hole DC/DC Converter, ITE, Industrial & Medical, SIP, 2 W, 1 Output, 5 V—

$9.18

$2.75

The Story

Product Overview

MDS02N-05N is a MDS02- N (New) series 2W isolated and unregulated module type medical grade DC- DC converter with SIP-7 package. Suitable for medical devices, medical oxygen monitor, CT scanning, medical carts, oral care equipment, telecom/ datacom system, wireless network, industrial control facility.

  • Input voltage range from 21.6 to 26.4V DC
  • Single output voltage of 5V DC
  • Comply with IEC/UL2368-1 and LVD IEC60601-1
  • Medical safety approved (1xMOPP/2xMOOP) according to IEC60601-1
  • Low patient leakage current <2µA
  • Protection: short circuit(continuous)
  • 6KV DC high I/O isolation (reinforced insulation)
  • Low cost
  • 3 years warranty
  • Operating temperature range from -40 to 95°C

Product details

Technical Specifications

Power Supply Applications

ITE, Industrial & Medical

Input Ratio

-

No. of Outputs

1 Output

Output Current - Output 1

400mA

Output Current - Output 2

-

Isolation Voltage

6kV

DC / DC Converter Output Type

Fixed

Height

11.5mm

Input Voltage DC Min

21.6V

Product Range

MDS02-N Series

DC / DC Converter Type

SIP

Output Power Max

2W

Output Voltage - Output 1

5V

Output Voltage - Output 2

-

Output Regulation

Unregulated

Input Voltage DC Nom

24V

Width

7.1mm

Depth

19.7mm

Input Voltage DC Max

26.4V

SVHC

No SVHC (21-Jan-2025)

Other details

Brand MEAN WELL
Part Number MDS02N-05N
Quantity Each
Technical Data Sheet EN Download technical document - datasheet - Tanotis India
