Kiloview U40 Overview
Add NDI connectivity to your existing camera as well as control your PTZ camera over an NDI or NDI|HX network with the Kiloview U40 4K60p HDMI to NDI Converter. The U40 is a disk like device, just over 3" in diameter and 1" tall, that packs quite a few features to simplify working with NDI|HX network. At that size, it's small enough to mount on your camera, using the included mounting shoe adapter, and it features an HDMI 2.0 input supporting 4K60p signals and converting them for connection to an NDI|HX network. The U40 also features two Ethernet ports which allow you to convert input IP streams into NDI|HX on your network.
The U40 supports PTZ control protocols, allowing you to use it to control your non-NDI|HX PTZ camera from your NDI|HX network, and you can also utilize the USB port for PTZ control via RS-232, RS-422, RS-485. A built-in tally light comes in handy to identify which camera you are controlling. It supports PoE power and has a handy power out feature, allowing you to power a camera or monitor.
Convert 4Kp60 HDMI to NDI
Support 3.5mm analog audio embedded in NDI
It also supports voice intercom based on optional Kiloview Intercom software
PoE with DC out, allowing you to power the U40, and at the same time, power other devices such as monitors, recorders, or cameras
Supports PTZ control USB to serial RS232/485/422
Supports Sony Visca / Visca (Laia) / Visca (Kato) / PELCO-D/PELCO-P protocols
USB video to NDI (future feature)
Convert IP streams such as RTSP/RTMP/SRT/TS-UDP/HLS to NDI|HX/SRT/RTSP/RTMP/TS-UDP
In the Box
- Kiloview U40 4K60p HDMI to NDI Converter
- 12 VDC 1A Power Adapter
- Cold Shoe
- Limited 1-Year Warranty
Kiloview U40 Specs
Input
| Video Input Connectors |
1 x HDMI (HDMI 2.0) |
| Input Video Format |
HDMI
UHD 4K: 60 fps |
| Audio Input Connectors |
1 x 1/8" / 3.5 mm TRS Analog |
Output
| Video Output Connectors |
2 x RJ45 |
| Audio Output Connectors |
None |
| HDR Compatibility |
Not Specified by Manufacturer |
Connectivity
| Other I/O |
1 x USB Type-A |
| Expansion Slots |
None |
IP Streaming
| Video IP Encoding |
RTMP, RTSP, UDP: x |
Power
| Power Connector |
1 x Barrel Input |
| Power Consumption |
Power Supply: 12 VDC at 1 A |
General
| Dimensions |
3.5 x 3.5 x 1.2" / 90 x 90 x 30Â mm |
| Weight |
10.9Â oz / 310Â g |
Packaging Info
| Package Weight |
1.2 lb |
| Box Dimensions (LxWxH) |
6.4 x 5.5 x 3.1" |
