Kemet C4AQCBW5200A3FJ DC Film Capacitor 20 µF 650 V PP (Polypropylene) ± 5% C4AQ Series Radial Box

C4AQ capacitors are made with polypropylene metallized film with rectangular plastic box-type design, filled with resin (white and grey color) and 2 or 4 tinned copper wires. Typical applications include DC filtering, DC link, power electronics, IGBT snubbers, energy storage, renewable energy grid interface, motor drives, and automotive applications.

• Self-healing
• Low losses
• High ripple current
• High capacitance density
• High contact reliability
• Automotive grade (AEC-Q200)

Product details

Capacitance	20µF
Voltage Rating	650V
Capacitor Dielectric Type	PP (Polypropylene)
Capacitance Tolerance	± 5%
Product Range	C4AQ Series
Capacitor Case Style	Radial Box
Capacitor Terminals	Radial Leaded
Lead Spacing	37.5mm
Operating Temperature Min	-40°C
Operating Temperature Max	105°C
Automotive Qualification Standard	AEC-Q200
RoHS Phthalates Compliant	Yes

Other details

Brand	KEMET
Part Number	C4AQCBW5200A3FJ
Quantity	Each
Technical Data Sheet EN
Product Change Notice EN
Manufacturer Catalogue EN
