-70%InFocus ScreenPlay Genesis II SP224ST 3800-Lumen XGA Short-Throw DLP Projector—
$1,279.09
$383.73The Story
InFocus SP224ST Overview
By Photo's
Frank Abbate
The InFocus ScreenPlay Genesis II SP224ST 3800-Lumen XGA Short-Throw DLP Projector is a compact and capable projector designed for use in offices and classrooms. The integrated short-throw lens can fill a 120" diagonal, 4:3 screen, from just 5' away, perfect for areas with limited space. Experience industry-leading lamp life with up to 15,000 hours when used in Dynamic mode. Connect devices via HDMI, VGA, and S-video inputs, including 3D sources, such as Blu-ray players or game consoles.
Additional Features
- Full 3D support
- USB-A to power HDMI dongles like Google Chromecast
- No filter to replace
- Digital edge masking and image shift
- RS-232 controllable
- 24/7 operation capable
Items Included
- InFocus ScreenPlay Genesis II SP224ST 3800-Lumen XGA Short-Throw DLP Projector
- Power Cable
- VGA Cable
- Remote Control
- Limited 2-Year Manufacturer Warranty (On Projector)
- Limited 1-Year Manufacturer Warranty (Or 1000 Hours on Original Lamp)
Additional Resources
InFocus SP224ST Specs
Key Specs
| Display System |
1-Chip 0.65" DMD DLP
|
| Native Resolution |
1024 x 768
|
| Maximum Brightness |
3800 Lumens
|
| Throw Ratio |
0.621:1 (120" Screen Size @ 5' / 1.5Â m)
|
| Projection Size |
30 to 300" / .8 to 7.6Â m
|
| HDR Support |
No
|
| Inputs/Outputs |
2x HDMI 1.4 Audio, Video Input
1x 4-Pin DIN (S-Video) Video Input 1x DE-15/DB-15 (VGA) Video Input 1x 1/8" / 3.5 mm Mini Audio Input 1x DE-15/DB-15 (VGA) Video Output 1x 1/8" / 3.5 mm Mini Audio Output 1x USB-A Power Output 1x DE-9/DB-9 (RS-232) Control Input |
| Light Source |
Lamp (1 x UHP)
|
Image Display
| Display System |
1-Chip 0.65" DMD DLP
|
| Native Resolution |
1024 x 768
|
| Supported Resolutions |
Maximum: 1920 x 1200
|
| Maximum Brightness |
3800 Lumens
|
| Uniformity |
80%
|
| Offset |
112.4%
|
| Aspect Ratio |
Native: 4:3
Supported: 16:10 Supported: 16:9 |
| Dynamic Contrast Ratio |
30,000:1
|
| DLP Link 3D |
Yes
|
| Supported 3D Formats |
Top Bottom
Side by Side Frame Sequential |
| Scan |
Horizontal: 15 to 97.55kHz
Vertical: 54 to 85Hz |
Lens
| Includes Lens |
Yes
|
| Focus |
Manual
|
| Aperture |
f/2.8
|
| Focal Length |
7.15mm
|
| Optical Zoom |
Manual: 1.1x
|
| Throw Distance |
1.25 to 12.5' / 0.38 to 3.8Â m
|
| Throw Ratio |
0.621:1 (120" Screen Size @ 5' / 1.5Â m)
|
| Projection Size |
30 to 300" / .8 to 7.6Â m
|
Features
| Keystone Correction |
Manual to Vertical: ± 20°
|
| HDR Support |
No
|
| Digital Zoom |
2x
|
| Multi-Input Support (PIP/PBP) |
No
|
| Ceiling Mountable |
Yes
|
| Rear Screen Projection |
Yes
|
| Built-In Speaker |
Yes (Mono)
|
| Speaker Power |
10 W
|
| Projection Tilt Option |
Yes
|
Input/Output Connectors
| Inputs/Outputs |
2x HDMI 1.4 Audio, Video Input
1x 4-Pin DIN (S-Video) Video Input 1x DE-15/DB-15 (VGA) Video Input 1x 1/8" / 3.5 mm Mini Audio Input 1x DE-15/DB-15 (VGA) Video Output 1x 1/8" / 3.5 mm Mini Audio Output 1x USB-A Power Output 1x DE-9/DB-9 (RS-232) Control Input |
| HDCP Support |
Yes
|
| Media/Memory Card Slot |
No
|
Hardware
| Mobile App Compatible |
No
|
| Wireless LAN / Wi-Fi |
No
|
| Bluetooth |
No
|
General
| Light Source |
Lamp (1 x UHP)
|
| Expected Lamp Life |
Low Brightness: 15,000 Hours
|
| Fan Noise |
Medium Brightness: 27 dB
|
| Security |
Cable Lock Slot
Keypad Lock |
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| Power Consumption |
Full Brightness: < 267 W
Low Brightness: 210 W Standby Mode (Lamp Off): < 0.5 W |
| Certifications |
CB, CE, EAC, cTUVus, CCC, FCC, UKCA, NOM, PSB, BIS
|
| Operating Conditions |
41 to 104°F / 5 to 40°C at 10 to 85% Humidity
|
| Storage Conditions |
14 to 140°F / -10 to 60°C at 10 to 85% Humidity
|
| Dimensions (W x H x D) |
12.3 x 3.8 x 9.3" / 313.0 x 96.4 x 236.0Â mm
|
| Weight |
6.4Â lb / 2.9Â kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
