$2.06
Original: $6.87
-70%Coilcraft POE70P-50LB POE70P-50LB Smps Transformer Flyback 1.4 A 250kHz 7 W 1.5 kV—
$6.87
$2.06The Story
The POE70P-50LB is a Flyback Transformer with ferrite core and tin-silver-copper over tin over nickel over phosphor bronze terminations. This transformer is developed for Powered Devices (PD) in IEEE 802.3af compliant PoE (3, 7 and 13W) applications.
- Designed to operate in continuous mode at 250kHz with an input of 36 to 72VDC
- 1500Vrms (1 minute) isolation from primary and bias to secondary
- 500Vrms (1 minute) isolation between all other windings
- 250kHz Switching frequency
- 12V, 20mA Bias winding output
Communications & Networking, Industrial
Other details
| Brand | COILCRAFT |
| Part Number | POE70P-50LB |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
