$1.06
Original: $3.52
-70%COILCRAFT MSS1048T-333MLB Surface Mount Power Inductor, MSS1048T Series, 33 �H, 2.8 A, 1.66 A, Shielded, 0.068 ohm—
$3.52
$1.06The Story
Applications
Automotive
Product details
| Inductance Tolerance | � 20% |
| RMS Current (Irms) | 2.8A |
| Saturation Current (Isat) | 1.66A |
| Power Inductor Case | 10.2mm x 10mm x 4.8mm |
| Inductance | 33�H |
| Inductor Construction | Shielded |
| Product Range | MSS1048T Series |
| DC Resistance Max | 0.068ohm |
| Packaging | Cut Tape |
Other details
| Brand | COILCRAFT |
| Part Number | MSS1048T-333MLB |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
