-70%COILCRAFT LPS4012-222MRB Surface Mount Power Inductor, LPS4012 Series, 2.2 µH, 1.2 A, 2.4 A, Shielded, 0.1 ohm—
$2.33
$0.70The Story
Applications
Automotive
Product details
| Inductance Tolerance | ± 20% |
| RMS Current (Irms) | 1.2A |
| Saturation Current (Isat) | 2.4A |
| Power Inductor Case | 3.9mm x 3.9mm x 1.1mm |
| Inductance | 2.2µH |
| Inductor Construction | Shielded |
| Product Range | LPS4012 Series |
| DC Resistance Max | 0.1ohm |
| Packaging | Cut Tape |
Other details
| Brand | COILCRAFT |
| Part Number | LPS4012-222MRB |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
