-70%CLIFF ELECTRONIC COMPONENTS FM686812 Circular Connector, Cliffcon 68 Series, Cable Mount Plug, 2 Contacts, Solder Socket—
$13.85
$4.15The Story
The FM686812 is a 2-way cable-mount Circular Female Plug with threaded coupling. This Cliffcon 68 series socket with gold-plated brass contacts, nylon 6.6 body, plastic shell. It is an IP68 rated connector for waterproof and rugged applications.
- 5 to 8mm Cable outer diameter
- -25�C to 85�C Temperature range
Applications
Industrial
Product details
| Connector Body Plating | - |
| No. of Contacts | 2Contacts |
| Contact Plating | Gold |
| Coupling Style | - |
| Circular Connector Shell Style | Cable Mount Plug |
| Product Range | Cliffcon 68 Series |
| Contact Material | Brass |
| Circular Contact Type | Solder Socket |
| Connector Body Material | Nylon 6.6 (Polyamide 6.6) Body |
Other details
| Brand | CLIFF ELECTRONIC COMPONENTS |
| Part Number | FM686812 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Description
The FM686812 is a 2-way cable-mount Circular Female Plug with threaded coupling. This Cliffcon 68 series socket with gold-plated brass contacts, nylon 6.6 body, plastic shell. It is an IP68 rated connector for waterproof and rugged applications.
- 5 to 8mm Cable outer diameter
- -25�C to 85�C Temperature range
Applications
Industrial
Product details
| Connector Body Plating | - |
| No. of Contacts | 2Contacts |
| Contact Plating | Gold |
| Coupling Style | - |
| Circular Connector Shell Style | Cable Mount Plug |
| Product Range | Cliffcon 68 Series |
| Contact Material | Brass |
| Circular Contact Type | Solder Socket |
| Connector Body Material | Nylon 6.6 (Polyamide 6.6) Body |
Other details
| Brand | CLIFF ELECTRONIC COMPONENTS |
| Part Number | FM686812 |
| Quantity | Each |
| Technical Data Sheet EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
