CHAUVET DJ Wedge Q3BT ILS Overview
Enjoy total freedom with the CHAUVET DJ EZLink Wedge Q3BT ILS, a battery-powered, true wireless RGBA (red, green, blue, and amber) LED light fixture with automated color mixing, full DMX control, and an integrated Bluetooth receiver. Designed to produce rich color washes for venue uplighting or dance-floors, mobile DJs can quickly position the fixture anywhere in the venue without running DMX or power cables. The innovative ILS technology allows this powerful par to be used with the ILS ecosystem, which makes creating coordinated light shows across an unlimited number of different fixture types fast and easy.
The built-in battery lasts up to 20 hours on a full charge in single-color mode or 9 hours with all colors on. Its compact design makes it easy to mount inside TRUSST Goal Post and Arch Kit truss systems. Operate as a standalone device with dynamic effects, including electronic dimming, color macros, variable-strobe, and built-in automated programs. It can also be controlled via DMX (4 or 8 channels) or used in a primary/secondary configuration to coordinate multiple fixtures without the need for a controller. Additionally, the fixture is compatible with the free BTAir application for smartphones and tablets. The EZLink Wedge Q3BT ILS is compatible with the optional IRC-6 remote control and ships with a power cord.
- 100% TRUE wireless, battery-operated, quad-color (RGBA) LED wash light with built-in Bluetooth wireless technology
- ILS compatibility for use in the ILS ecosystem
- Control directly from a smartphone or tablet without any additional hardware
- Convenient, wireless non-DMX control using the IRC-6 remote
- The wedge-shaped design makes it fit perfectly inside TRUSST Goal Post and Arch Kit truss systems
- Generate a broad spectrum of colors and natural-looking color temperatures with punchy amber LEDs
- Attaches to truss without the need for a bracket, using M10 or M12 threaded rig points
- Save time running cables and extension cords by power linking multiple units
Items Included
- CHAUVET DJ EZLink Wedge Q3BT ILS TRUE Wireless RGBA LED Wash Light with Bluetooth
- Power Cord
- Limited 2-Year Manufacturer Warranty
Additional Resources
CHAUVET DJ Wedge Q3BT ILS Specs
| Fixture Type |
LED Panel
|
| Light Source |
3x Color LED - 5 W / 1.4 A
|
| Colors |
Amber, Blue, Green, Red
|
| Beam Angle |
13°
|
| Control Protocols |
DMX512, Internal
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power / Current Consumption |
120 VAC, 60 Hz: 30 W / 0.5 A
230 VAC, 50 Hz: 28 W / 0.5 A |
| Mounting |
Floor Base, M10 Threaded, M12 Threaded
|
| Fixture Type |
LED Panel
|
| Light Source |
3x Color LED - 5 W / 1.4 A
|
| Expected Lamp Life |
50,000 Hours
|
| Colors |
Amber, Blue, Green, Red
|
| Photometrics |
130 fc / 1400 Lux at 6.6' / 2 m
|
| Beam Angle |
13°
|
| Field Angle |
25°
|
| Shutter / Strobe |
Electronic
|
| Iris |
No
|
| Zoom Adjustment |
No
|
| Dimming |
Electronic, 0 to 100%
|
| Operating Modes |
Automatic, DMX, Primary/Secondary, Sound-Active, Static Color
|
| Macros / Programs |
Auto-Program
Sound-Active Fade |
| Effects |
Strobe
|
| Strobe Rate |
0 to 20 Hz
|
| Gobos |
No
|
| Control Protocols |
DMX512, Internal
|
| DMX Channel Modes |
2 Mode(s):
4 / 8-Channel |
| Display / Controls |
LED / 4-Button
|
| Remote Control |
IR Remote (with Optional Equipment)
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: BTAir Functionality: Remote Control |
| Wireless |
Bluetooth / IR
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Not Specified by Manufacturer
|
| Power / Current Consumption |
120 VAC, 60 Hz: 30 W / 0.5 A
230 VAC, 50 Hz: 28 W / 0.5 A |
| Power Linking |
16 Units at 120 VAC
23 Units at 230 VAC |
| Battery Type |
Lithium
|
| Approximate Battery Life |
All On: Up to 9 Hours
Single Color: Up to 20 Hours |
| Battery Charging Time |
5 Hours
|
| Environmental Resistance |
Dust-Resistant (IP20)
|
| Operating Conditions |
Up to 104°F / 40.0°C
|
| Mounting |
Floor Base, M10 Threaded, M12 Threaded
|
| Included Accessories |
1x Power Cable
|
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Certifications |
CE, RoHS, UKCA, FCC
|
| Dimensions |
6.8 x 4.3 x 4.3" / 17.3 x 10.9 x 10.9 cm
|
| Weight |
2 lb / 0.9 kg
|
| Package Weight |
2.875 lb
|
| Box Dimensions (LxWxH) |
9.3 x 6.4 x 6.4"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
