-70%CAMDENBOSS CTB92VG/2S Pluggable Terminal Block, 5 mm, 2 Ways, 30 AWG, 12 AWG, 2.5 mm�, Screw—
$3.16
$0.95The Story
The CTB92VG/2S is a 2-pole 320V/12A female pluggable rising clamp Terminal Block with UL94-V0 flame retardant PA green polarised moulding, tinned phosphor bronze pin/terminal, nickel copper flash brass rising clamp, M3 steel zinc plated captive screw, vertical orientation, 5mm pitch. It features anti solder wicking and guided pin alignment. It accepts 0.2 to 2.5mm� (30 to 12AWG) solid and stranded cable.
- >=2.5kV Dielectric strength
- 4kV Impulse withstand voltage
- 0.5Nm Torque
- 1.4mm Recommended PCB hole size
Applications
Industrial
Product details
| Wire Size AWG Max | 12AWG |
| Wire Connection Method | Screw |
| Rated Current | 12A |
| No. of Positions | 2Ways |
| Conductor Area CSA | 2.5mm� |
| Product Range | CTB92VG Series |
| Pitch Spacing | 5mm |
| Wire Size AWG Min | 30AWG |
| Rated Voltage | 320V |
Other details
| Brand | CAMDENBOSS |
| Part Number | CTB92VG/2S |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
