-70%BOURNS SDR0604-180YL Surface Mount Power Inductor, SDR0604 Series, 18 µH, 1.25 A, 1.5 A, Unshielded, 0.15 ohm—
$0.73
$0.22The Story
This is a Surface Mount Power Inductor, SDR0604 Series, 18 µH, 1.25 A, 1.5 A, Unshielded, 0.15 ohm product from BOURNS with the model number SDR0604-180YL
Product details
| Product Range | SDR0604 Series |
| Inductance | 18µH |
| RMS Current (Irms) | 1.25A |
| Saturation Current (Isat) | 1.5A |
| Inductor Construction | Unshielded |
| DC Resistance Max | 0.15ohm |
| Power Inductor Case | 5.8mm x 5.8mm x 4.8mm |
| Inductance Tolerance | ± 15% |
| Packaging | Cut Tape |
Other details
| Brand | BOURNS |
| Part Number | SDR0604-180YL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
