ANALOG DEVICES LTC6993CS6-1#TRMPBF Pulse Generator, Monostable, Rising-Edge, 2.25 V to 5.5 V, 0 to 70 Deg C, TSOT-23-6

LTC6993-1 is a monostable multivibrator (also known as a one-shot pulse generator) with a programmable pulse width of 1µs to 33.6 seconds. The LTC6993 is part of the TimerBlox® family of versatile silicon timing devices. A single resistor, RSET, programs an internal oscillator frequency, setting the LTC6993�s time base. The output pulse is initiated by a transition on the trigger input (TRIG). Typical applications are watchdog timer, frequency discriminators, missing pulse detection, envelope detection, high vibration, high acceleration environments, portable and battery-powered equipment.

• Pulse width range from 1µs to 33.55seconds
• Configured with 1 to 3 resistors
• Rising-edge input polarity, non-retriggerable
• Fast recovery time
• Operating supply voltage range from 2.25 to 5.5V
• 70µA supply current at 10µs pulse width
• 500µs start-up time
• 6-lead plastic TSOT-23 package
• 0°C to 70°C temperature rating

Notes

ADI products are only authorized (and sold) for use by the customer and are not to be resold or otherwise passed on to any third party
