-70%3M 10314-3210-000 Connector Backshell, Plastic Shielded Junction Backshell—
$9.20
$2.76The Story
The 10314-3210-000 is a 14-way 0.050-inch plastic shielded Junction Shell for round cable. This 103 series durable one piece plastic over two piece metal junction backshell can be used with mini D Ribbon 101XX-6000 EC plug connectors. Outer shell made of ABS, inner shell made of steel (0.5mm thick) with nickel-plated finish.
- Beige colour
- Quick release latching
- UL94V-0 Flame-rated outer shell
Applications
Industrial
Product details
| Accessory Type | Plastic Shielded Junction Backshell |
| Connector Shell Size | 14 |
| Product Range | 10314 Series |
| For Use With | Mini D Ribbon 101XX-6000 EC Plug Connectors |
| Cable Exit Angle | 180� |
| Connector Body Material | ABS (Acrylonitrile Butadiene Styrene) Body |
Other details
| Brand | 3M |
| Part Number | 10314-3210-000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
